S18M-5-K-32 Datalogic Photoelectric Sensor

Material PBT Accuracy 100% Active Area 10 mm Operating temperature -25 ..... 60 C Brand Datalogic Model No. S18M-5K-32 Product Type Photoelectric Sensor Color Silver Weight 59 g Power supply: 10 ... 30 Vdc, reverse polarity protection Consumption: 30 mA max. Light emission: infrared LED 880 nm red LED (B vers.) Diffuse proximity operating distance: 1 ... 30 cm (C vers.) 1 ... 10 cm (K vers.) Retroreflex operating distance: 0.1 ... 2 m (on R2) Polarised retroreflex operating distance: 0.1 ... 1.5 m (on R2) Through beam operating distance: 0 ... 12 m Setting: sensitivity trimmer (B, C vers.) Indicators: yellow OUTPUT LED green POWER LED (G vers.) Output type: NPN or PNP, open conifigurable (4 wires vers.) Saturation voltage: 2.5 V max. (4 wires vers.) 1.8 V max. (3 wires vers.) Output current: 150 mA max., short-circuit protection
