S3-S-E1 Datalogic Fiber Optical Amplifire

🔧 Datalogic S3-S-E1 Proximity Sensor | High-Precision Sensing for Industrial Use

The Datalogic S3-S-E1 is a compact and versatile proximity sensor engineered for demanding industrial automation applications. Constructed from rugged PBT plastic, it delivers 100% detection accuracy and supports multiple sensing configurations, including diffuse, retroreflective, and through-beam modes.

⚙️ Technical Specifications:

• Brand: Datalogic

• Model Name/Number: S3-S-E1

• Sensor Type: Proximity Sensor

• Body Material: PBT Plastic

• Sensing Distance: 8 mm (Active Area)

• Accuracy: 100%

• Response Frequency: 50 Hz

• Power Supply Voltage: 10 – 30 V DC (with reverse polarity protection)

• Current Consumption: 30 mA max.

• Light Emission: Infrared 880 nm / Red LED 660 nm (E1 Version)

• Operating Temperature: Not specified (typical for industrial use)

📏 Sensing Performance:

• Diffuse Proximity (C10): 0 – 10 cm

• Diffuse Proximity (C50): 0 – 50 cm

• Fixed Focus (D12): 12 mm focus with 1 mm spot

• Polarized Retroreflective: 0.1 – 2 m (on R2 reflector)

• Retroreflective for Transparent Objects: 0.2 – 0.8 m

• Through-Beam Mode: 0 – 5 m

• With Fibre Optics (OF-18-S): Up to 33 mm proximity

✅ Key Features:

• Compact M18 design for easy installation

• Infrared and visible red LED options for flexible sensing

• Multiple optical configurations support diverse applications

• Rugged build quality for industrial durability

• Reverse polarity protection for reliable power management

Whether you're automating complex production lines or optimizing sensing for clear object detection, the Datalogic S3-S-E1 provides the versatility, precision, and reliability you need.
