SA4110 IFM Flow Sensor

Line Size 1 inch Application Media Water Model Name/Number SA4110 SAEXXXXBFRKG/US-100 Number of inputs and outputs Number of digital outputs: 2; Number of analogue outputs: 1 Process connection clamp adapter 8 mm Special feature Gold-plated contacts Media water; glycol solutions; air; oils Operating voltage [V] 18-30 dc Measuring principle calorimetric Electrical design PNP/NPN Output function normally open / normally closed; (parameterisable) Weight [g] 296.5 Housing cylindrical Measurement of flow and temperature at the same time Optimised for water, oils and air Red/green display for clear identification of the acceptable range With switching output, analogue signal and IO-Link The process connection can be rotated for optimum alignment
