SA6010 IFM Flow Sensor

Line Size 1 inch Model Name/Number SA6010 SAN12XDBFRKG/US-100 Number of inputs and outputs Number of digital outputs: 2; Number of analogue outputs: 1 Process connection threaded connection 1/2" NPT external thread Special feature Gold-plated contacts Operating voltage [V] 18-30 DC Measuring principle calorimetric Electrical design PNP/NPN Number of digital outputs 2 Output function normally open / normally closed; (parameterisable) Weight [g] 251.5 Housing cylindrical Probe diameter [mm] 5 MM Measurement of flow and temperature at the same time Optimised for water, oils and air Red/green display for clear identification of the acceptable range With switching output, analogue signal and IO-Link The process connection can be rotated for optimum alignment
