SBG233 IFM Flow Meter

SBG233 Stainless Steel Digital Flow Meter | 1.5" Line Size | IP65 | IO-Link Compatible

The SBG233 Flow Meter is engineered for precision, durability, and seamless integration into your liquid monitoring systems. Built with a stainless steel body, this flow meter is ideal for monitoring water, coolants, oils, and glycol solutions—making it a reliable choice for demanding industrial applications.

With an intuitive digital display, integrated backflow prevention, and IO-Link connectivity, the SBG233 delivers accurate flow and temperature measurements, enhanced by integrated measurement graphs for consistent performance across various media.

⚙️ Technical Specifications:

• Material: Stainless Steel

• Line Size: 1.5 Inch

• Display: Digital

• Model Number: SBG233

• Power Supply: 18 – 36 V

• Operating Voltage: 10 – 30 V

• Flow Range: 50 Bar

• Max Operating Pressure: 200 Bar

• Frequency: 50 Hz

• Temperature Range: -25°C to +70°C

• Protection Rating: IP65

• Weight: 750 g

• Packaging Type: Box

• Application Media: Any Liquid (including water, oils, coolants, and glycol solutions)

✅ Key Features:

• Precise flow and medium temperature detection

• Reliable backflow prevention with fast response

• Switching, analogue, frequency output, and IO-Link connectivity

• Clearly visible digital LED display with red/green color indication

• Integrated measurement graphs for enhanced accuracy across different media

• Durable design with high pressure resistance and IP65 protection

SBG233 is your all-in-one solution for accurate, fast, and intelligent liquid flow monitoring. Ideal for industrial automation, process control, and critical liquid management systems.
