SF5703 IFM Flow Sensor

Sensor Type Ultrasonic Part Number SF5703 SFD10ADT /US-100 Application Industrial Material Stainless Steel Probe length L 143 Process connection threaded connection M18 x 1,5 internal thread Media Liquids; Gases; aggressive media Pressure rating 10 MPa Connection to control monitor VS3000 Setting range 200-3000 Greatest sensitivity 200-800 Temperature gradient 300 Reliable monitoring of liquids and gases in pipes For connection to an evaluation unit Simple process connection via adapter Titanium materials for contact with the medium for use in aggressive media M12 connector for fast and easy connection
