DBS36E-S3EK02048 Sick Incremental Encoder

Brand Sick Material Stainless Steel Model/Type DBS36E-S3EK02048 Encoder Type Incremental Shaft Diameter 6 mm x 12 mm Operating Voltage Range 7 V...30 V Initialization Time 3 ms Load Current Max 30 mA Pulses Per Revolution 2048 Shaft Material Stainless Steel Sick DBS36E-S3EK02048 Incremental Encoder, Sick DBS36 Incremental Encoder DBS36E-S3EK02048 Specification/Additional Details Brand : Sick Encoder Type : Incremental Shaft Diameter : 6 mm x 12 mm Model : DBS36E-S3EK02048 Operating Voltage Range : 7 V~30 V Initialization Time : < 3 ms Load Current Max. : 30 mA Pulses Per Revolution : 2,048 Shaft Material : Stainless Steel Housing Material : Aluminum Maximum Operating Speed : 8,000 U/min Measuring Step : 90 Degree / electronically/pulses Start up Torque : 0.5 Ncm (+20 DegreeC) Mechanical Interface : Solid Shaft, Face Mount Flange Maximum Output Frequency : 300 kHz Operating Torque : 0.4 Ncm (+20 DegreeC)
