SKIIP-942GB120-3DK0103 SEMIKRON IGBT

Voltage 600 V Part Number 942GB120-3DK0103 Model Name/Number 942GB120-3DK0103 Dimensions 30x86x53 Storage temperature -40 ... 75 Absolute Maximum Ratings Symbol Conditions Values Unit VS2 Power supply 1) 13 ... 30 V Top Operating temperature 2) 0 ... 70 °C Tstg Storage temperature -40 ... 75 °C Characteristics Symbol Conditions min. typ. max. Unit VS2 Power supply 13 24 30 V IS0 Supply current (no load)3) @ 24V 15 mA IS2 Supply current (max load)3) @ 24V 50 mA td(on)IO Input-output turn-on signal propagation time 0.17 µs td(off)IO Input-output turn-off signal propagation time 0.27 µs td(err) Error input-output propagation time 10 µs IFdc Transmitter current4) 53 mA ?PEAK Peak emission wave length 660 nm w weight with housing 33 g HxWxD Dimensions 30x86x53 mm
