SM4120 IFM Flow Meter

Line Size 1 inch Model Name/Number SM4120 SMR14XGXFRKG/US-100 Number of inputs and outputs Number of digital outputs: 2; Number of analogue outputs: 1 Process connection threaded connection G 1/4 external thread DN6 flat seal Special feature Gold-plated contacts Measuring principle magnetic-inductive Electrical design PNP/NPN Output function normally open / normally closed; (parameterisable) Weight [g] 706.9 Housing rectangular Dimensions [mm] 110 x 48 x 73 Precise measurement of flow, consumption and medium temperature High accuracy, repeatability and measurement dynamics With switching output, analogue output and pulse output Clearly readable colour display with red/green colour change No inlet and output pipe lengths required
