SN04-P RIKO Proximity Sensor

🔍 Riko SN04-P PNP Proximity Sensor | 15mm Sensing Distance | IP65

Achieve precise and reliable object detection in industrial environments with the Riko SN04-P Proximity Sensor. This high-accuracy sensor is designed with robust PBT plastic housing, a 15mm sensing distance, and a PNP normally open output—ideal for demanding automation systems.

⚙️ Product Specifications:

• Model: SN04-P

• Sensing Distance: 15 mm

• Output Type: PNP, Normally Open (NO)

• Response Frequency: 50 Hz

• Voltage Range: 10–30 V DC

• Operating Current: 10 mA

• Max Switching Current: 30 mA

• Control Output: 10–30 VDC

• Power Supply Residual Voltage:

  • Max 1.5V (DC three-wire)

  • Max 6V (DC two-wire)

• Current Consumption:

  • Max 12 mA (DC three-wire)

  • Max 0.9 mA (DC two-wire)

• Load Current Capacity:

  • Max 200 mA (three-wire)

  • Max 100 mA (two-wire)

• Switching Function: Normally Open (NO)

• Accuracy: 100%

• Case Material: Brass

• Detecting Surface: ABS

• Body Material: PBT Plastic

💡 Indicators & Protection:

• LED Indicators:

  • Red LED: Output indicator

  • Green LED: Power status

• Protection Circuits:

  • Reverse Polarity Protection

  • Surge Absorber

• Insulation Resistance: Min. 50 MΩ (500VDC)

• Degree of Protection: IP65 (dust tight & water jet protected)

🌡️ Environmental Specs:

• Operating Temperature: -20°C to +70°C

✅ Applications:

• Industrial automation

• Robotics and motion control

• Conveyor systems

• Object detection and presence sensing

Built for performance, engineered for durability. The Riko SN04-P Proximity Sensor ensures stable operation and easy integration into your automation setup.
