SN0500 IFM Control Monitor | Industrial Automation Monitoring | KMSPARE

Sensor Type Ultrasonic Brand IFM Part Number SN0500 VS3000/85...265VAC Application Industrial Material Stainless Steel Frequency AC [Hz] 47...63 Operating voltage tolerance [%] -5...10 Operating voltage [V] 90...240 AC Protection class II Power-on delay time [s] 10...80; (adjustable (fixed-value resistors terminals 22-23)) Number of channels 1 Contact rating 4 A (250 V AC / 30 V DC) Protection IP 20 Weight 252.5 Dimensions 100 x 25 x 103.5 For the connection of flow sensors Integrated flow, temperature and wire monitoring Adjustable switching outputs for monitoring flow and temperature Clearly visible multi-colour LED bargraph display Signal output via potential-free relay contacts
