SR1-1250-N Autonics Solid State Relays

Autonics SR1-1250-N Solid State Relay Board | 6-Channel, 50A, DC to AC / DC to DC

The Autonics SR1-1250-N is a high-capacity 6-channel solid state relay board, engineered for demanding industrial environments. With zero-cross turn-on switching, high dielectric strength, and reliable performance across a wide temperature range, this relay board is ideal for efficient control of high-power AC loads through DC inputs.

🔧 Key Features:

• Model: SR1-1250-N

• Brand: Autonics

• Relay Type: DC to AC / DC to DC

• Channels: 6

• Control Phase: Single Phase

• Rated Input Voltage: 4 – 30 VDC

• Rated Load Voltage: 24 – 240 VAC~ (50/60 Hz)

• Rated Load Current: 50 A

• Relay Current: 15 mA

• Current Capacity: 50 A

• Function: Zero Cross Turn-On

• Dielectric Strength: 2500 VAC~ for 1 min (Input-Output, Input/Output-Case)

• Mounting Type: Industrial Panel Mount

• Voltage Type: DC Input

• Power Supply: 5 V

• Material: PBT (Polybutylene Terephthalate)

• Color: Black

• Product Net Length: 2 meters

• Weight: 111 g

• Operating Temperature Range: -30°C to +80°C

• Part Number: SR1-1250-N

• Accuracy: 100%

✅ Applications:

Perfect for:

• High-load AC switching in control panels

• Motor drives and HVAC systems

• Industrial automation systems

• Electrical and process control in multi-phase setups

Ensure smooth, noise-free operation with the Autonics SR1-1250-N—a powerful, multi-channel relay board built for precision, safety, and durability in industrial environments.
