SR1-4275 Autonics Solid State Relays

🔌 Autonics SR1-4275 Solid State Relay | 75A | 90–240V AC Input | Industrial Grade

The Autonics SR1-4275 is a high-capacity Solid State Relay (SSR) engineered for industrial applications requiring reliable switching and long service life. Supporting both DC to AC and DC to DC functions, it handles up to 75A load current with an input voltage range of 90–240V AC.

Built with a durable PBT body, this relay ensures excellent insulation and heat resistance for demanding operational environments. It is perfect for three-phase power systems and integrates easily via industrial mounting.

📦 Product Specifications:

• Model Name/Number: SR1-4275

• Brand: Autonics

• Type: Solid State Relay (SSR)

• Voltage Type: DC

• Input Voltage: 90–240V AC

• Rated Load Voltage: 24–240V AC

• Rated Load Current: 75A

• Relay Trigger Current: 15 mA

• Channels: 6

• Control Phase: 3 Phase

• Mounting Type: Industrial Mounting

• Material: PBT (Polybutylene Terephthalate)

• Operating Temperature: -25°C to +70°C

• Product Net Length: 2 m

• Dielectric Strength: 2500V

• Accuracy: 100%

• Color: Black

✅ Key Features:

• ✔ High Load Capacity: Supports Up to 75A

• ✔ DC to AC & DC to DC Switching

• ✔ Wide Input Voltage Range: 90–240V AC

• ✔ Compact 6-Channel Design

• ✔ Robust PBT Housing for Industrial Use

• ✔ Suitable for 3-Phase Power Applications

• ✔ Dielectric Strength of 2500V for Safe Operation

Enhance your industrial control systems with the Autonics SR1-4275, a dependable SSR that delivers power, efficiency, and safety in one compact unit.
