SSR-75DA Fotek Solid State Relay

⚡ Fotek SSR-75DA Solid State Relay – High-Performance Industrial Switching

Ensure reliable, noise-free switching in your industrial applications with the Fotek SSR-75DA. This robust AC to DC solid state relay is engineered for long-term durability, optimal safety, and efficient performance in high-demand environments.

🔧 Technical Specifications:

• Brand: Fotek

• Model Number: SSR-75DA

• Voltage Type: AC

• Input Voltage: 4–32 VDC

• Output Voltage: AC Load (90–480V typical)

• Trigger Current: ≤12 mA

• Turn-Off Voltage: ≤3.5 VDC

• Control Method: Zero Cross

• Leakage Current: ≤5 mA

• Response Time: 8.3 ms (at 60Hz)

• Relay Current: 75A

• Mounting Type: Industrial Mounting (1-Phase)

• Operating Temperature: -40°C to +80°C

• Housing Material: PBT/ABS UL 94V-0 Rated

• Color: Silver

• Weight: 98 g

• Insulation Strength: 100MΩ / 500VDC

• Isolation Strength: 4 KVrms (EN60950/VDE0805)

• Input Immunity: 2 KV (EN61000-4-4)

• Ideal For: AC to DC conversion in control systems

✅ Key Features:

• 🔒 Zero-Cross Switching – Reduces electrical noise and ensures smooth operation

• 🌡️ Wide Operating Temp (-40°C to +80°C) – Reliable performance in extreme environments

• 🧱 High-Strength ABS Housing – Fire-resistant and industrial-grade durability

• ⚙️ Quick Response Time – 8.3 ms for fast switching

• 🔌 Industrial-Ready Design – Perfect for panel integration and automation systems

• ⚡ High Isolation & Insulation – Meets global safety standards

🏭 Ideal For Use In:

• Industrial automation

• Temperature control systems

• Motor drives

• Lighting controls

• HVAC systems

Upgrade your control panel with the Fotek SSR-75DA — your go-to solid state relay for stable, safe, and efficient industrial switching.
