SU18-40A/102/115A/123 P&F Fiber Optic Sensor

🔦 P&F SU18-40a/102/115a/123 Fiber Optic Sensor Head – High-Speed, Compact Detection with IO-Link

Upgrade your industrial automation with the P&F SU18-40a/102/115a/123 Fiber Optic Sensor Head—engineered for fast, reliable, and precise object detection. Designed with a robust stainless steel M12 housing and IO-Link compatibility, this compact sensor delivers superior performance even in demanding environments.

🔧 Technical Specifications:

• Brand: P&F (Pepperl+Fuchs)

• Model Number: SU18-40a/102/115a/123

• Type: Fiber Optic Sensor Head

• Light Source: Red LED

• Interface: IO-Link

• Switching Output: PNP

• Switching Frequency: 50 / 60 Hz

• Supply Voltage (UB): 10–30 V DC

• Switching Voltage: 30 V

• Switching Current: 10 mA

• No Load Supply Current: 30 mA

• Housing Type: M12

• Housing Material: Stainless Steel

• Degree of Protection: IP67 / IP50

• Operating Temperature: -25°C to +70°C

• Dimensions (H x W x D): 34.5 x 9 x 62.3 mm

💡 Key Features:

• High switching frequency for rapid detection cycles

• 3 selectable response times for application flexibility

• External TEACH-IN for quick and easy calibration

• Rugged stainless steel housing with IP67 protection—ideal for harsh environments

• Slim, DIN rail mountable design saves panel space

• IO-Link enabled for smart diagnostics and real-time configuration

🛠 Application Areas:

• Industrial automation

• Robotics and motion control

• Assembly lines

• Compact control cabinets

• High-speed production monitoring

Boost the speed and accuracy of your detection system with the P&F SU18-40a/102/115a/123 Fiber Optic Sensor Head—perfectly built for modern industrial needs.
