TL-Q5MB1-Z Omron Proximity Sensor

Omron TL-Q5MB1-Z Proximity Sensor – Durable, Reliable, Industrial-Grade Detection

The Omron TL-Q5MB1-Z is a high-performance proximity sensor engineered for industrial applications that demand reliable, precise, and durable sensing. With a stainless steel body and IP67 protection, it delivers excellent resistance to harsh environmental conditions.

Designed for non-contact metal detection, this sensor offers a sensing distance of 5 mm ±10%, fast response times, and a compact 17 x 17 x 28 mm housing—perfect for tight installation spaces.

📦 Product Highlights:

• Brand: Omron

• Model: TL-Q5MB1-Z

• Sensor Type: Proximity Sensor

• CAD Type: 2D

• Sensing Distance: 5 mm ±10%

• Control Output: PNP

• Power Source: DC, Three-wire

• Power Supply Voltage: 10–30 V DC

• Maximum Switching Current: 10 mA

• Leakage Current Load: 15 mA

• Operating Frequency: 50 / 60 Hz

• Ambient Temperature Range: -25°C to +70°C

• Storage Temperature: -25°C to +75°C

• Ambient Humidity (Storage): -15°C to +55°C

• Material: Stainless Steel

• Protection Rating: IP67

• Usage/Application: Industrial

• Dimension (W x H x L): 17 mm x 17 mm x 28 mm

• Thread Length: 2 m

• Type: Square, Unshielded

⚙️ Key Features:

• Robust stainless steel housing for enhanced durability

• Compact design ideal for limited-space installations

• Fast and accurate detection of metal objects

• IP67-rated protection for dust and water resistance

• Consistent performance across a wide temperature range

Enhance your automation setup with the Omron TL-Q5MB1-Z — built to deliver precision sensing, long-term reliability, and superior protection in tough industrial environments.
