TLU-015 Datalogic Colour Mark Sensor

Detection Distance 10mm Brand Datalogic Sensing Method Colour Mark Model Number TLU-015 Application Industrial Sensing Distance 10 mm Response time 2 ms Connection Type M12 Supply Voltage 12 to 24 V DC Housing Material Plastic Degree of Protection IP67 Operating Temperature -40 to 125 Deg C IP Rating IP64 Weight 450 g Power supply 10 .......... 30 V Switching Output PNP/NPN Power supply: 10 … 30 Vdc limit values; reverse polarity protection Ripple: 2 Vpp max. Current consumption (output current excluded): 80 mA max. Output: NPN or PNP, pull down/up resistance 10 k? (short-circuit protection) Output current: 200 mA max. Analog output: 0 … 2 V ± 10% (white 90%); 5.5 V max.; ripple 40 mVpp max.; output resistance 2.2 k? Output saturation voltage: 1V max. NPN versions / 2V max PNP versions Response time: 50 µs max. / 25 µs max. (TLµ-4xx/5xx) Switching frequency: 10 kHz max. / 20 kHz max. (TLµ-4xx/5xx) Timing function: 20 ms minimum output ON Indicators: OUTPUT LED (RED) / READY LED (GREEN) Setting: by pushbuttons / by wires; 4 settings storage cable version Retention data: non volatile EEPROM memory Operating temperature: -10 … 55 °C Storage temperature: -20 … 70 °C Electric shock protection: Class 1 Operating distance: 9 mm (TLµ-x1x/4xx/5xx) / 18 mm (TLµ-x6x)
