TS5700-N8505-SN-A01478 TAMAGAWA Rotary Encoder

Encoder Type Rotary Resolution 360 CPR Brand Servo Model Name/Number TS5700 N8505 SN A01478 Supply Voltage DC+5 V +-5 % Protective Structure IP40 Absolute encoders output the absolute value of rotation angles.The encoders are used for position control of servo motors mounted on machine tools or robots.As shown in Figure 2, rotation slits are lined from the center on concentric circles. Slits indicates binary code strings of 2 pulses/rev from the center.Multi-turn absolute encoders memorize the rotation quantity data over one rotation.
