U500.DA0.2-11200629 Baumer Ultrasonic Sensor

Baumer Inductive Sensor – 40 mm Sensing Distance, High-Precision, qTeach & Line-Teach, Compact Design

The Baumer Inductive Sensor offers highly accurate, fast, and reliable detection in industrial automation environments. With a scanning range of 70–1000 mm, fast response times, and intelligent qTeach & Line-Teach adjustment, this sensor is built for precision performance in compact, rugged form.

🔧 Technical Specifications:

• Brand: Baumer

• Sensor Type: Inductive

• Sensing Distance: 40 mm

• Scanning Range (Sd): 70–1000 mm

• Scanning Range Close Limit (Sdc): 70–1000 mm

• Scanning Range Far Limit (Sde): 70–1000 mm

• Supply Voltage: 12–30 V DC

• Supply Current: 35 mA

• Sonic Frequency: 200 kHz

• Response Time (Ton): < 40 ms

• Release Time (Toff): < 40 ms

• Repeat Accuracy: < 0.5 mm

• Resolution: < 0.3 mm

• Temperature Drift: < 2% of distance to target (So)

• Power-Up Drift: Compensated after 15 min

• Working Temperature Range: -45°C to +70°C

• Housing Material: PBT Plastic

• Color: Black

• Frequency: 3 kHz

• Accuracy: 100%

• Alignment Measuring Axis: < 2°

⚙️ Key Features:

• ✅ 40 mm Sensing Distance – Ideal for medium-range object detection

• ✅ qTeach & Line-Teach Configuration – Simplifies setup and calibration

• ✅ High Repeat Accuracy & Resolution – < 0.5 mm repeatability and < 0.3 mm resolution

• ✅ Compact, Rugged Design – Durable plastic housing for industrial use

• ✅ LED Indicators:

  • Yellow LED (Flashing): Alignment and output status

  • Green LED: Power-on indication

• ✅ Fast Response Times (< 40 ms) – For real-time automation tasks

• ✅ Temperature Drift Compensation – Ensures stable measurements over time

🏭 Ideal For:

• Conveyor and packaging systems

• Robotics and precision machinery

• Material positioning and part presence detection

• OEM sensor integrations

• Automated quality control systems

Designed for reliability and engineered for precision, this Baumer 40 mm Inductive Sensor is an excellent choice for fast-paced, accuracy-demanding industrial applications.
