U500.PA0-11110577 Baumer Ultrasonic Proximity Sensor

Sensing Distance 100 mm Sensor Type Inductive Housing Material PBT Supply Current 35 mA Supply Voltage 10 ....... 30 V Brand Baumer Material PBT Color Black Working Temperature -45 ......... 75 C Usage/Application Industrial Accuracy 100% Dimension Mm 10 mm Frequency Hz 3 kHz canning range Sd 100 ... 1000 mm scanning range far limit Sde 100 ... 1000 mm hysteresis typ. 4 % Sde repeat accuracy < 0,5 mm temperature drift < 2 % Sde power-up drift compensated after 15 min. response time ton < 50 ms release time toff < 50 ms sonic frequency 220 kHz adjustment qTeach alignment aid light indicator flashing light indicator LED yellow power on indication LED green alignment measuring axis < 2°
