U500.PA0-11110577 Baumer Ultrasonic Proximity Sensor

Baumer Inductive Sensor – 100 mm Sensing, High Precision, qTeach Programmable, IP Rated

The Baumer Inductive Sensor offers reliable, high-accuracy detection for demanding industrial automation environments. Built with a rugged PBT housing, this sensor features a wide scanning range (100–1000 mm), fast response time, and integrated qTeach programming for intuitive configuration.

🔧 Technical Specifications:

• Brand: Baumer

• Sensor Type: Inductive

• Sensing Distance: 100 mm

• Scanning Range (Sd): 100 – 1000 mm

• Scanning Range Far Limit (Sde): 100 – 1000 mm

• Supply Voltage: 10 – 30 V DC

• Supply Current: 35 mA

• Sonic Frequency: 220 kHz

• Response Time (Ton): < 50 ms

• Release Time (Toff): < 50 ms

• Repeat Accuracy: < 0.5 mm

• Hysteresis (typical): 4% of Sde

• Temperature Drift: < 2% of Sde

• Power-Up Drift: Compensated after 15 min

• Accuracy: 100%

• Working Temperature: -45°C to +75°C

• Housing Material: PBT Plastic

• Color: Black

• Dimensions: 10 mm

• Frequency: 3 kHz

• Alignment Measuring Axis: < 2°

⚙️ Key Features:

• ✅ qTeach Programming – Simplifies setup with one-touch adjustment

• ✅ LED Indicators:

  • Yellow LED: Flashing for alignment aid and switching state

  • Green LED: Power-on indication

• ✅ Compact 10 mm Housing – Fits tight industrial spaces

• ✅ High-Speed Performance – Fast <50 ms response and release time

• ✅ Excellent Repeat Accuracy (< 0.5 mm) – For precision applications

• ✅ Wide Temperature Range – Operates from -45°C to +75°C

• ✅ Temperature Drift Compensation – Ensures stable long-term operation

🏭 Ideal Applications:

• Industrial automation systems

• Robotics and machinery alignment

• Conveyor control and part detection

• OEM sensor integration

• High-precision presence and distance monitoring

Engineered for precision and built for durability, this Baumer Inductive Sensor offers outstanding performance across a wide detection range with programmable convenience and fast response—ideal for your most demanding industrial applications.
