UB1000-18GM75-E6-V15 P&F Ultrasonic Sensor

P&F UB1000-18GM75-E6-V15 Ultrasonic Sensor – Dual Switch Outputs, 15 mm Sensing Distance, IP67

The UB1000-18GM75-E6-V15 from Pepperl+Fuchs (P&F) is a high-performance ultrasonic sensor designed for precision in industrial automation environments. Built with a nickel-plated brass body and stainless steel construction, this sensor offers durability, flexibility, and pinpoint accuracy — even in challenging conditions.

🔧 Key Specifications:

• Model Number: UB1000-18GM75-E6-V15

• Sensor Type: Ultrasonic

• Sensing Distance: 15 mm

• Output Type: 2 switch outputs (with 3 configurable output functions)

• Switching Frequency: 255 kHz

• Response Frequency: 255 kHz

• Power Supply Voltage: 10 – 30 V DC

• Accuracy: 100%

• Body Material: Brass, nickel-plated (stainless steel finish)

• Protection Rating: IP67 – Water and dust resistant

• Weight: Approx. 65 g

• Use Case: Industrial automation, object detection, level monitoring

⚙️ Advanced Features:

• Selectable Sound Lobe Width: Customize the detection beam for different application needs

• Program Input: Easily configure sensor settings

• Temperature Compensation: Consistent performance in varying environments

• Very Small Unusable Area: Maximizes detection capability, even at close range

• Compact Cylindrical Design: Easy to install in tight industrial spaces

🏭 Industrial Applications:

• Conveyor & packaging systems

• Automated production lines

• Robotic positioning

• Liquid level detection

• Object detection in harsh environments

Built for reliability and versatility, the UB1000-18GM75-E6-V15 is the ideal ultrasonic sensor for modern industrial automation. Get consistent, accurate results with minimal downtime — even under tough operating conditions.
