UB200-12GM-U-V1 P&F Ultrasonic Sensor

P&F UB200-12GM-U-V1 Ultrasonic Sensor – Analog Output (0–10 V), Compact Design, IP67 Rated

The UB200-12GM-U-V1 Ultrasonic Sensor by Pepperl+Fuchs (P&F) is engineered for precision analog measurement in industrial environments. With an adjustable measuring window, compact design, and durable stainless steel construction, this sensor is ideal for applications that demand high accuracy and reliability.

🔧 Technical Specifications:

• Brand: Pepperl+Fuchs (P&F)

• Model Number: UB200-12GM-U-V1

• Sensor Type: Ultrasonic

• Sensing Distance: 10 mm

• Sensing Range: 15 mm to 200 mm

• Output Type: Analog (0–10 V)

• Switching Frequency: 60 Hz

• Response Frequency: 400 kHz

• Nominal Voltage: 15–30 V DC

• Power Supply Voltage: Up to 30 V DC

• Accuracy: 100%

• Material: PBT Plastic Sensor Housing, Stainless Steel Body

• Ambient Temperature Range: -25°C to +55°C

• Protection Rating: IP67 – Dust-tight and water-resistant

⚙️ Key Features:

• ✅ Analog Output (0–10 V) – Ideal for precise distance and level measurements

• ✅ Adjustable Measuring Window – Tailor the detection range to your needs

• ✅ Very Small Unusable Area – Enables close-range object detection

• ✅ Temperature Compensation – Ensures accuracy in variable climates

• ✅ Program Input – Quick and easy configuration

• ✅ Compact, Durable Design – Fits into tight industrial installations

• ✅ High Response Frequency (400 kHz) – Fast and reliable data output

🏭 Recommended Applications:

• Industrial automation

• Liquid level sensing

• Material positioning systems

• Robotics and conveyor control

• Non-contact distance measurement

Compact, powerful, and configurable, the UB200-12GM-U-V1 is built for professionals who demand high-performance sensing in challenging industrial environments.
