UB500-18GM75-E01-V15 P&F Ultrasonic sensor

P&F UB500-18GM75-E01-V15 Ultrasonic Sensor – Analog Output (4–20 mA), Adjustable Range, IP67 Rated

The UB500-18GM75-E01-V15 Ultrasonic Sensor by Pepperl+Fuchs (P&F) is a high-precision, industrial-grade sensor designed for accurate, non-contact distance measurement. With an analog output of 4–20 mA, adjustable measuring window, and robust IP67 protection, this sensor is ideal for a wide range of demanding applications.

🔧 Key Specifications:

• Model Number: UB500-18GM75-E01-V15

• Sensor Type: Ultrasonic

• Sensing Distance: 10 mm

• Output Type: Analog (4 mA to 20 mA)

• Switching Frequency: 50–70 Hz

• Power Supply Voltage: 30 V DC

• Accuracy: 100%

• Body Material: Stainless Steel

• Sensor Housing: PBT Plastic

• Weight: 60 g

• Ambient Operating Temperature: -40°C to +70°C

• Protection Class: IP67 – Fully sealed against dust and water

⚙️ Advanced Features:

• ✅ Analog Output (4–20 mA) – Ideal for continuous measurement applications

• ✅ Adjustable Measuring Window – Fine-tune detection range as needed

• ✅ Selectable Sound Lobe Width – Optimize detection beam for various targets

• ✅ Program Input – Quick and easy configuration

• ✅ Synchronization Options – Integrate with other sensors in complex systems

• ✅ Deactivation Option – Temporarily disable sensor without power off

• ✅ Temperature Compensation – Ensures reliable performance in varying conditions

• ✅ Very Small Unusable Area – Enables close-range detection

🏭 Perfect for Industrial Applications Including:

• Tank level monitoring

• Conveyor and material handling systems

• Robotics and machine integration

• Packaging automation

• Distance and position sensing

The UB500-18GM75-E01-V15 offers exceptional flexibility, durability, and performance in harsh industrial environments. If your application demands precision analog sensing, this sensor is the ideal choice.
