UB500-18GM75-E4-V15 P&F Ultrasonic Sensor

P&F UB500-18GM75-E4-V15 Ultrasonic Sensor – 8 mm Sensing Distance, Programmable, IP67 Rated

The UB500-18GM75-E4-V15 Ultrasonic Sensor by Pepperl+Fuchs (P&F) offers advanced, non-contact object detection for industrial applications. Built with a stainless steel body and IP67 protection, it’s engineered for performance in demanding environments — combining accuracy, adaptability, and reliability in a compact, rugged form.

🔧 Technical Specifications:

• Model: UB500-18GM75-E4-V15

• Sensor Type: Ultrasonic

• Sensing Distance: 8 mm

• Sensing Range: Typically 30–500 mm

• Switching Frequency: 380 kHz

• Nominal Voltage: 10–30 V DC

• Power Supply Voltage: Up to 30 V DC

• Accuracy: 100%

• Body Material: Stainless Steel

• Sensor Housing: PBT Plastic

• Ambient Operating Temperature: -25°C to +70°C

• Protection Class: IP67 – Dust-tight and waterproof

• Output Type: Switching output

• Weight: Approx. 65 g

⚙️ Advanced Features:

• ✅ 5 Configurable Output Functions – Adapt to various applications

• ✅ Selectable Sound Lobe Width – Adjust beam for precise detection

• ✅ Program Input – Easy setup and parameterization

• ✅ Synchronization Options – Coordinate with other sensors

• ✅ Deactivation Option – Temporarily disable the sensor when needed

• ✅ Temperature Compensation – Consistent accuracy in changing environments

• ✅ Very Small Unusable Area – Detect objects closer than ever before

🏭 Ideal Applications:

• Conveyor and sorting systems

• Robotic guidance and safety

• Packaging automation

• Level measurement in tanks

• General industrial object detection

The UB500-18GM75-E4-V15 is more than just a sensor — it’s a flexible solution designed for today’s automated industries. Whether you need precision, adaptability, or rugged durability, this sensor delivers.
