UGT513 IFM Ultrasonic Sensor

IFM UGT513 Ultrasonic Sensor – 8 mm Sensing Distance | IO-Link | IP67 Rated

The IFM UGT513 Ultrasonic Sensor (UGA02200E1KG/IO-LINK/US) is an advanced, high-accuracy sensor designed for demanding industrial applications. Its robust stainless-steel cylindrical housing allows for flush installation, while non-contact detection ensures reliable performance regardless of an object’s color, surface texture, or material.

🔧 Technical Specifications:

• Brand: IFM

• Model: UGT513

• Sensor Type: Ultrasonic

• Sensing Distance: 8 mm

• Output Type: PNP (Switching & Analog Output Programmable)

• Switching Mode: NO / NC

• Switching Frequency: 50 / 60 Hz

• Response Frequency: 60 Hz

• Body Style: Cylindrical – M18 x 1

• Length: 97.5 mm

• Installation: Flush Mount

• Material: Stainless Steel

• Supply Voltage: 10 – 30 V DC

• Power: 0.3 W

• Connection Type: Cable

• Number of Wires: 2-Wire

• Protection Rating: IP67

• Operating Temperature: -40°C to +105°C

• Control Output Voltage: 30 V

• Interface: IO-Link

• LED Indicators: For switching status and echo detection

✅ Key Features:

• Wide Detection Range: Accurate sensing with programmable output and scalable analog output

• Smart Setup: Intuitive Teach-in functionality and advanced IO-Link connectivity for seamless configuration

• Non-Contact Sensing: Operates effectively on all object types—regardless of transparency or color

• Industrial Durability: IP67-rated stainless steel housing withstands harsh environments and wide temperature ranges

• Versatile Integration: Ideal for industrial automation, object positioning, and packaging systems

Upgrade your industrial sensing capabilities with the IFM UGT513 Ultrasonic Sensor, offering reliability, smart connectivity, and precision in a compact form factor.
