UGT580 IFM Ultrasonic Sensor

IFM UGT580 Ultrasonic Sensor – 10 mm Sensing Distance | PNP Output | IP67 Rated

The IFM UGT580 Ultrasonic Sensor is a high-performance, space-saving solution for precise object detection in industrial environments. Designed with a rugged metal housing and flush installation, it ensures non-contact sensing of targets regardless of surface color, material, or transparency.

🔧 Technical Specifications:

• Brand: IFM

• Model Number: UGT580 (UGQ00300E1KG/US)

• Sensor Type: Ultrasonic

• Sensing Distance: 10 mm

• Output Type: PNP (Switching & Analog Output Programmable)

• Switching Mode: NO / NC

• Switching Frequency: 50 / 60 Hz

• Installation Type: Flush

• Body Material: Stainless Steel (Cylindrical Housing)

• Connection Type: Cable

• Number of Wires: 2-Wire

• Protection Rating: IP67 (Sensor Head) / IP64 (Overall)

• Power Supply Voltage: 10 – 30 V DC

• Current Consumption: 35 mA

• Operating Temperature: -40°C to +105°C

• Converter Frequency: 300 kHz

• Dimensions: 53 x 20 x 37.7 mm

✅ Key Features:

• Space-Saving Design: Robust rectangular housing with side-mounted M18 thread—perfect for tight installation spaces

• Precise Detection: 10 mm sensing range with scalable analog and programmable switching outputs

• Material-Independent: Accurately detects objects regardless of color, reflectivity, or material

• Easy Configuration: Teach-in button allows for intuitive range setup

• Reliable Operation: Built for harsh industrial conditions with wide temperature range and high ingress protection

• Dual Output Flexibility: Combines switching and analog output for enhanced control integration

Whether you're integrating this sensor into compact machinery, automated inspection systems, or material handling setups, the IFM UGT580 delivers consistent, contactless performance with advanced configuration options.
