UNAM-70I6131-S14 Baumer Ultrasonic Distance Measuring Sensor

Baumer Ultrasonic Sensor – 40mm Sensing Distance | High Accuracy Industrial Detection

Enhance your automation precision with the Baumer Ultrasonic Sensor, engineered for reliable and accurate object detection in industrial environments. With a robust PBT housing, wide temperature tolerance, and high sensing range, this sensor delivers top-tier performance in even the harshest applications.

🔧 Key Specifications:

• Brand: Baumer

• Sensor Type: Ultrasonic

• Sensing Distance: 40 mm

• Scanning Range (Sd): 600 – 6000 mm

• Scanning Range Close Limit (Sdc): 600 – 6000 mm

• Scanning Range Far Limit (Sde): 600 – 6000 mm

• Supply Voltage: 10 – 30 V DC

• Supply Current: 35 mA

• Frequency: 3 kHz | Sonic Frequency: 80 kHz

• Resolution: < 2 mm

• Repeat Accuracy: 3 mm

• Response Time (ton/toff): < 640 ms

• Temperature Drift: < 2% of Sde (>50 mm)

• Housing Material: Durable PBT

• Color: Black

• Weight: 30 g

• Operating Temperature: -45°C to +70°C

• Accuracy: 100%

• Adjustment: Teach-in

• Alignment Aid: Target indication with flashing

✅ Features:

• Precise distance measurement with ±2 mm resolution

• Long-range scanning up to 6000 mm

• Compact & durable PBT housing ideal for industrial use

• Teach-in adjustment for quick setup and calibration

• Visual alignment aid with flashing target indicator

• Excellent temperature stability and resistance to harsh conditions

Perfect for factory automation, robotics, and process control systems, the Baumer Ultrasonic Sensor provides consistent, high-accuracy detection across varied industrial applications.
