XCKM116LC Telemecanique Limit Switch

Contact Configuration
SPDT
Switch Type
Micro Limit Switch
Rated Voltage
440 VAC
Mounting Type
Top Mounted
Model Name/Number
XCKM116LC
Operating Frequency
60 Hz
Ambient Operating Temperature
70 C
Weight
313 g
Standards
EN 60947-5-1
Product weight
0.28 Kg
Width
64 mm
Height
64 mm
Depth
30 m
Main Range of product Telemecanique Limit switches XC Standard Series name Standard format Product or component type Limit switch Device short name XCKM Body type Fixed Head type Rotary head Material Metal Body material Zamak Fixing mode By the body Movement of operating head Rotary Type of operator Spring return roller lever thermoplastic Type of approach Lateral approach, 2 directions Cable entry 3 entries tapped for Pg 11 cable gland Number of poles 2 Contacts type and composition 1 NC + 1 NO Contact operation Snap action
