XCKP2121G11X1 Telemecanique Limit Switch

Contact Configuration
SPDT
Switch Type
Rotary Limit Switch
Rated Voltage
240 VAC
Mounting Type
Side Mounted
Model Name/Number
XCKP2121G11X1
Operating Frequency
50 / 60 Hz
Ambient Operating Temperature
-30 ..........+80 C
Ambient Operating Humidity
-20 .........+80 C
Switching Frequency
60 Hz
Operating Accuracy Block
100 %
Degree Of Protection
IP50
Width
31 mm
Height
65 mm
Depth
30 mm
Net weight
105 g
Range of product Telemecanique Limit switches XC Standard Series name Standard format Product or component type Limit switch Device short name XCKP Sensor design Compact form E conforming to CENELEC EN 50047 Body type Fixed Head type Plunger head Material Plastic Body material Plastic Head material Zamak Fixing mode By the body Movement of operating head Linear Type of operator Spring return roller lever plunger thermoplastic Type of approach Lateral approach, 1 direction Number of poles 2 Contacts type and composition 1 NC + 1 NO Contact operation Snap action
