ZC-Q2255 Omron Limit Switch

Switch Type
Rotary
Rated Voltage
240 VAC
Model Name/Number
ZC-Q2255
Operating Frequency
50 / 60 Hz
Packaging Type
Box
Ambient Operating Temperature
-40 ....... 70 C
Product Type
Limit Switch
Degree Of Protection
IP67
Contact form
SPDT
Current
35 mA
Permissible operating frequency Electrical: 20 operations / 1 minute max.
Mechanical: 120 operations / 1 minute max.
Contact resistance (Initial value) 15 mΩ max. (initial value for the built-in switch whentested alone)
Insulation resistance 100 MΩ min. (at 500 VDC)
Dielectric strength Between each terminal of the same polarities: 1,000 VAC 50/60 Hz 1 min
Between each terminal and non-live-metallic part: 2,000 VAC 50/60 Hz 1 min
Durability Electrical: 500,000 operations min.
Mechanical: 10 million operations min.
Vibration resistance Malfunction: 10 to 55 Hz, 1.5 mm double amplitude, Contact opening: 1 ms max. at the free position and the total travel position.
Shock resistance Destruction: 1,000 m/s2 max.
Degree of protection IP67
